BEALE AFB



TITAN I

MISSILE BASE CONSTRUCTION

851st STRATEGIC MISSILE SQUADRON

BEALE  AFB

MARYSVILLE, CALIFORNIA



UNITED STATES ARMY CORPS OF ENGINEERS

CONSTRUCTION HISTORY PHOTOS

AERIAL SITE 1A  LINCOLN





AERIAL SITE 1A  LINCOLN





SITE 1A  LINCOLN





LAUNCHER #1

AERIAL SITE 1A  LINCOLN





ANTENNA SILOS

AERIAL SITE 2A  LIVE OAK / SUTTER BUTTES





POWER HOUSE

AERIAL SITE 2A  LIVE OAK / SUTTER BUTTES





AERIAL SITE 1C  CHICO





INSTRUMENTATION





MISSILE PLACEMENT





IN THE NEAR FUTURE I HOPE TO ACQUIRE ORIGINAL COPIES



EXCAVATION OF LAUNCHER  #1   LINCOLN



TUNNEL EXCAVATION

SITE 1C



EXCAVATION OF LAUNCHER #1

SITE 1A





OPEN CUT EXCAVATION

SITE 1B TAKEN MARCH 1, 1960



OPEN CUT EXCAVATION LAUNCHER #2

SITE 1C



REMOVING ROCK FROM POWERHOUSE AREA

SITE 1A



EARTH SLIDE NEAR LAUNCHER #2

SITE 1A



OPEN CUT EXCAVATION

LAUNCHER #2  TAKEN IN MARCH 1960

SITE 1A



ANTENNA SILOS OPEN CUT EXCAVATION

SHORING OF SLOPE

SITE 1A



OPEN CUT EXCAVATION OF POWERHOUSE AND

CONTROL CENTER

SITE 1C



SHAFTING OPERATION EQUIPMENT

LAUNCHER #1

SITE 1A





ROCK BOLT DRILLING

SITE 1A



SHAFTING  OPERATIONS SHOWING STEEL

RING BEAMS AND APPLYING GUNITE

LAUNCHER #1

SITE 1A



LINER PLATE

LAUNCHER #2

SITE 1A



ROCK BOLTS SEEN UNDER CONTROL CENTER

SITE 1A



ROCK BOLTS BEING PLACED UNDER

CONTROL CENTER

SITE 1A



ROCK BOLTS CLOSE UP UNDER

CONTROL CENTER

SITE 1A



ROCK BOLTS

SITE 1A



BUCKLED LINER PLATE INSIDE LAUNCHER

SITE 1A



COMPACTING BACKFILL AROUND

ANTENNA  SILOS

SITE 1A



BACKFILLING

SITE C



TUNNEL BACKFILL BETWEEN JUNCTION 10 AND

ANTENNA TERMINAL

SITE 1A



TUNNEL BACKFILLING

SITE 1A



CONCRETE BATCH PLANT

SITE 1A



CONCRETE PLACEMENT MISSILE SILO NUMBER 2

SITE  1A



SETTING FORMS FOR ANTENNA SILOS

SITE  1C



FORMING PROPELLANT TERMINAL

SITE  1C



FORMING MISSILE SILO NUMBER 2

SITE  1A



FORMING EQUIPMENT TERMINAL WALL

SITE  1A



FORMING MISSILE SILO TOP SLAB

SITE  1A



MOVABLE STEEL FORMS SURROUND THE CONTROL CENTER

SITE  1A



MOVABLE STEEL FORMS BEGIN TO TAKE SHAPE FOR CONTROL CENTER

SITE  1A



MOVABLE STEEL FORMS BEGIN THE POWERHOUSE

SITE  1A



SLIP FORMS BEING PLACED IN MISSILE SILO #1

SITE  1A



SLIP FORMS BEING PLACED IN MISSILE SILO #1

SITE  1A



SLIP FORMS BEING PLACED IN MISSILE SILO #1  NOTICE THE BUGGIE, HOPPER AND HOIST BUCKET

SITE  1A



CONCRETE WALL FINISHING MISSILE SILO #1

SITE  1A



REINFORCEMENT STEEL  MISSILE SILO #1 NOTICE LOX HEATING AND VENTILATING TUNNEL OPENINGS

SITE  1A



REINFORCEMENT STEEL FOR AIR EXHAUST

SITE  1A



REINFORCEMENT STEEL ANTENNA SILOS

SITE  1A



REINFORCEMENT STEEL FOR FOUNDATION OF LIQUID OXYGEN TANK

SITE  1C



LIQUID OXYGEN FUEL CRIB FOR MISSILE SILO #1

SITE  1B



SPRING BEAMS IN POWERHOUSE

SITE  1C



SPRING BEAMS FOR POWERHOUSE GENERATOR SLAB

SITE  1A



SPRING BEAMS FOR CONTROL CENTER

SITE  1C



COIL SPRING MOUNTS FOR PROPELLANT TERMINAL

SITE  1A



SPRING BEAMS IN EQUIPMENT TERMINAL #1

SITE  1A



PROPELLANT TERMINAL LOOKING INTO INTERCONNECTING TUNNEL

NOTICE SEALED PIPE ENDS AND PURGE SET UP



LOX CRIB MISSILE SILO AT INTERCONNECTING TUNNEL LEVEL.  NOTICE INTERIM PIPING INSTALLATION



LOX CRIB IN THE MISSILE SILO.  NOTICE THE CATCH POT INSTALLATION



FUEL CRIB IN MISSILE SILO

RP-1 FLOW CONTROLLER AND AIR RELEASE TANK INSTALLATION



TUNNEL JUNCTION 12

FUEL TRANSFER PANEL



TUNNEL JUNCTION 12

FUEL CONTROL VALVES AND PIPING INSTALLATION



INTERCONNECTING TUNNEL  NOTICE FIELD INSTALLATION SET-UP



COMPLETED INTERCONNECTING TUNNEL INSTALLATION



PROPELLANT TERMINAL

MAIN DECK PIPING INSTALLATION FOR LOX TANK SAFETY VALVE MANIFOLD



PROPELLANT TERMINAL

MAIN DECK VALVES AND CONNECTIONS TAPED FOR LEAK CHECK DURING TESTING



PROPELLANT TERMINAL MAIN DECK

COMPLETED INSTALLATION OF LOX TANK SAFETY VALVE MANIFOLD

NOTICE TRANSFER PANELS IN BACKGROUND



PROPELLANT TERMINAL MAIN DECK

INTERIM LOX CONTROL VALVE INSTALLATION



PROPELLANT TERMINAL MAIN DECK

COMPLETED VALVE INSTALLATION AND TRANSFER PANELS



PROPELLANT TERMINAL LOWER LEVEL

FLEX HOSE AND PIPE SUPPORT INSTALLATION



PROPELLANT TERMINAL

HIGH PRESSURE GASEOUS BOTTLE CLUSTER AND CONTROL MANIFOLD



RADIATION SHIELD BETWEEN VENT SHAFT AND INTERCONNECTING TUNNEL



PROPELLANT LOADING SYSTEM TESTING EQUIPMENT

HIGH PRESSURE RECHARGER AND LIQUID NITROGEN STORAGE TANK
