579th STRATEGIC MISSILE SQUADRON
ATLAS F
WALKER, AFB
SITE 1
INVESTIGATION BOARD MEMBERS VIEWING THE INTERIOR DAMAGE
NOTE: THE SITE WAS A TOTAL LOSS
THE MISSILE SILO DOORS LAY 99 AND 109 FEET TO THE EAST AND WEST
UPPER LEVEL LAUNCH CONTROL CENTER
NOTE: DUST FOLLOWING BLAST
LOWER LEVEL LAUNCH CONTROL CENTER
NOTE: LAUNCH CONSOLE IN CENTER OF PHOTOGRAPH
FIRE AND DEBRIS DOOR LEADING FROM UTILITY TUNNEL TO LAUNCH CONTROL CENTER
NOTE: VERY LITTLE DAMAGE PRESENT
FIRST BLAST DOOR LEADING TO MISSILE SILO
CABLE TRAYS WITH BURNED/MELTED WIRING
NOTE: THESE CABLE TRAYS ARE LOCATED BETWEEN THE BLAST DOORS LEADING TO THE MISSILE SILO
THE INTENSE HEAT HAS FUSED SOME METALS TOGETHER
NOTE: THIS METAL IS STILL HOT
